HT12

The HIGHTOP HT12 is a 1,200 kg tracked mini excavator powered by a 10.2 kW Kubota D722 engine. Its 896 mm chassis width suits narrow-access digging, trenching and landscaping work.

Machine weight: 1,200 kg
Engine model: Kubota D722
Maximum power: 10.2 kW @ 2,500 rpm
Bucket capacity: 0.025 m³

Machine highlights

Key features and dimensions.

896 mm chassis width

The narrow tracked chassis is suited to gateways, side passages and restricted landscaping areas where access is the first constraint.

Kubota D722 power

The three-cylinder Kubota diesel produces 10.2 kW at 2,500 rpm for digging and hydraulic work.

Compact digging envelope

The HT12 reaches 1,650 mm deep, 2,850 mm at ground level and 1,850 mm at maximum dump height.

Key specifications

HT12 at a glance.

Machine specifications in one place. Final values can vary by configuration, market and attachment package.

Machine weight: 1,200 kg
Engine model: Kubota D722
Maximum power: 10.2 kW @ 2,500 rpm
Bucket capacity: 0.025 m³
Bucket width: 380 mm
Maximum digging depth: 1,650 mm
Vertical digging depth: 1,375 mm
Maximum digging height: 2,610 mm
Maximum dump height: 1,850 mm
Maximum ground reach: 2,850 mm
Travel speed: 1.5 km/h
Overall dimensions: 2,770 × 896 × 1,490 mm
Track width: 180 mm

Before deciding

Specifications do not tell the whole story.

Check service access, parts availability, warranty terms, controls, build quality and the exact configuration before choosing a machine.
